Type 6 COMe Core Board
➢ High-performance Intel Alder Lake-P series Intel 12th Gen. CPU
➢ Dual-channel DDR5 memory, support up to 64GB/4800MT/s
➢ Support 3x DDI, can be configured as HDMI/DVI/DP; 1 eDP/LVDS
➢ 16x PCIe Gen4, 5x PCIe Gen3 channels
➢ Type6 design with a compact size of 95*95*2.0mm
Model | ECM-6121 | |||||
Form Factor | Form Factor | COMe Type6 Core Board | ||||
Processor System | CPU | 7305E | i5-1250PE | i5-1350PE | i7-1360P | i3-1315U |
Core Number | 5C | 12C | 12C | 12C | 6C | |
Total Threads | 5T | 16T | 16T | 16T | 8T | |
Max. Speed | 1.0GHz | 4.4 GHz | 4.6 GHz | 5.0 GHz | 4.5GHz | |
L2 Cache | 8M | 12M | 12M | 18M | 10M | |
TDP (W) | 15W | 28W | 28W | 28W | 15W | |
BIOS | AMI UEFI 256 Mbit | |||||
Expansion Slot |
PCI Express | PEG: PCIe Gen4, 12 lanes (H series), Bitfurcate to 1 x8 PEG: PCIe Gen4, 4 lanes (P/U series), Bitfurcate to 1 x4 PCIe: PCIe Gen3, 8 lanes max up to 6 end devices, Default 5 lanes (5 x1, 2 x2 + 1 x1), Option 2 x4, 1 x4 + 2 x2 (Co-lay with SATA & Ethernet) | ||||
Memory | Type | DDR5 Non-ECC | ||||
Max. Capacity | 64G 4800MH/s | |||||
Socket | 2 x SO-DIMM | |||||
Display | Multiple Display | 4 Ports | ||||
Controller | LVDS Dual Chanel(Option eDP) 3 x DDI configurable HDMI/DisplayPort | |||||
Resolution | LVDS:1920*1200@60Hz HDMI2.0b:4096*2160@60Hz 24bpp DP1.4a:4096*2304@60Hz 36bpp eDP:4096*2304@60Hz 24bpp | |||||
Ethernet | Controller | Intel®I225-AT | ||||
Speed | 10M/100M/1000M/2.5Gbps | |||||
Internal Connector | SATA | 2 x SATA3.0(6Gbps) | ||||
USB 3.2 | 4 x USB 3.2(10Gbps) | |||||
USB 2.0 | 8 x USB2.0(480Mbps) | |||||
COM | 2 x COM | |||||
GPIO | 8-bits GPIO | |||||
Watch Dog | 65536 Level, 0~65535 sec | |||||
Others | 1、1 x LPC 2、1 x SMBUS 3、1 x SPI 4、Smart Fan 2 Ports 5、1 x I2C | |||||
Connector | 2 x COM-E 220Pin Connector | |||||
Power Requirements | Power Type | ATX: VCC,VSB AT: VCC | ||||
Power input Voltage | Vin: 8.5V~20V(±5%) VSB: 5±5% RTC Battery: 2.0V~3.3V | |||||
Connector type | Power provided by Base board | |||||
Environment | Operating Temperature | 0~60℃ | ||||
Storage Temperature | 0~60℃ | |||||
Operating Humidity | 40℃@95% Relative Humidity, Non-condensing | |||||
Storage Humidity | 60℃@95% Relative Humidity, Non-condensing | |||||
Physical | Dimensions | 95*95mm | ||||
PCB Color | Green | |||||
OS | Microsoft | Support | ||||
Linux | Support | |||||
